主要特性与技术指标
- 10 MHz 到 50 GHz
- 2 端口或 4 端口，具有两个内置信号源
- 126 dB 系统动态范围和 129 dB 接收机动态范围、32,001 点、32 通道、5 MHz IF 带宽
- 高输出功率（+16 dBm）、低谐波（-60 dBc）和宽功率扫描范围（41 dB）
- 最佳动态精度――在接收机端使用 0.1 dB 压缩和 +15 dBm 输入功率
- 在 10 Hz IFBW 时仅有 -111 dBm 的低本底噪声
描述
全球最广泛的单次连接测量应用软件
PNA-X 网络分析仪是全球功能最全、最灵活的单次连接微波测试引擎，可测量放大器、混频器和频率转换器等有源器件。目前它提供以下五种频率型号供您选择：13.5、26.5、43.5、50 和 67 GHz，可满足您特定的器件测试需求。PNA-X 具有内置的第二个信号源、合路器和内部信号路由开关，能够提供无与伦比的可配置性。取代机架和堆叠
PNA-X 可以取代机架安装式和堆叠式设备，减少您需要使用的设备数量。应用软件包括：
· S 参数（连续波和脉冲）
· 噪声系数
· 增益压缩
· 互调和谐波失真
· 转换增益/损耗
· 真正差分激励
· 毫米波
· 非线性波形和 X 参数®表征
· 天线测试
选件：
| N5245A-008 | Pulsed-RF Measurements |
| N5245A-010 | Time-domain measurements |
| N5245A-020 | Add IF inputs |
| N5245A-021 | Add pulse modulator to internal first source |
| N5245A-022 | Add pulse modulator to internal second source |
| N5245A-025 | Add four internal pulse generators |
| N5245A-028 | Noise figure measurements using standard receivers |
| N5245A-029 | Fully-Corrected Noise-Figure Measurements to 50 GHz |
| N5245A-080 | Frequency offset measurements |
| N5245A-082 | Scalar calibrated converter measurements |
| N5245A-083 | Vector and scalar calibrated converter measurements |
| N5245A-084 | Embedded LO measurements |
| N5245A-086 | Gain compression application |
| N5245A-087 | Intermodulation distortion measurements |
| N5245A-088 | Source phase control |
| N5245A-118 | Fast CW mode |
| N5245A-1A7 | Calibration + Uncertainties + Guardbanding |
| N5245A-1CM | Rack mount kit for installation without handles |
| N5245A-1CP | Rack mount kit for installation with handles |
| N5245A-200 | 2 ports, single source |
| N5245A-219 | Add extended power range and bias-tees to 2 port analyzer |
| N5245A-224 | Add internal second source, combiner and mechanical switches to 2-port analyzer |
| N5245A-301 | Application for use with standard CalPods |
| N5245A-302 | Application for use with temperature-characterized CalPods |
| N5245A-400 | 4 ports, dual source |
| N5245A-419 | Add extended power range and bias-tees to 4 port analyzer |
| N5245A-423 | Add internal combiner and mechanical switches to 4-port analyzer |
| N5245A-460 | Integrated true-mode stimulus application |
| N5245A-510 | Nonlinear component characterization, full frequency range |
| N5245A-514 | Nonlinear X-Parameters |
| N5245A-518 | Nonlinear pulse envelope domain |
| N5245A-520 | Arbitrary load impedance X-parameters |
| N5245A-551 | N-port calibrated measurements |
| N5245A-897 | Built-in performance test software for inclusive calibration, perpetual license |
| N5245A-898 | Built-in performance test software for standards compliant calibration, perpetual license |
| N5245A-A6J | ANSI Z540-1-1994 Calibration |
| N5245A-H08 | Pulsed - RF Measurements |
| N5245A-UK6 | Commercial calibration certificate with test data |
| N1966A | Pulse/IO Adapter |
| N6171A | MATLAB Software |
| N6171A-M01 | MATLAB-Basic Package, individual license - node-locked |
| N6171A-M02 | MATLAB-Standard Package, individual license - node-locked |
| N6171A-M03 | MATLAB-Advanced Package, individual license - node-locked |
质量保障，成色新颖，并且承诺给您的价格是业内最低
